Purpose And Characteristics
① High strength aluminum alloy housing;
② The oil inlet and outlet can be selected in the following ways: rear in front out, side in side out, rear in rear out, etc;
③ Automatic axial clearance compensation mechanism enables the oil pump to maintain high volumetric efficiency for a long time;
④ Widely used in micro power unit hydraulic systems.
Model Description
① Company Code
② Classification code
③ Pressure rating [F: 20Mpa]
④ Nominal displacement (mL/r)
⑤ Rotation direction S: left rotation; D: Dextral rotation
⑥ See Appendix for shaft extensions and flanges
⑦ See the appendix for the form of oil port
⑧ Front and rear cover material [G: cast iron]
Outline Drawing
Performance Parameter
