Purpose And Characteristics
① High strength ductile iron pump body;
② The input shaft is connected with flat keys, rectangular splines, and involute splines;
③ The connection forms of oil inlet and outlet include threads, flanges, etc. to choose from;
④ Automatic axial clearance compensation mechanism enables the oil pump to maintain high efficiency for a long time;
⑤ High working pressure, wide rotational speed range, and high volumetric efficiency at low rotational speeds up to 600 rpm.
Model Description
① Company Code
② Classification code
③ Pressure rating (F: 20MPa)
④ Nominal displacement (mL/r)
⑤ Rotation direction S: left rotation; D: Dextral rotation
⑥ Shaft extensions and flanges [see appendix]
⑦ Oil port type [see appendix]
⑧ Front and rear cover material G: cast iron
⑨ Pump body material G: cast iron
Outline Drawing
Performance Parameter
